The Cudy POE200 1.0 is a compact, plug‑and‑play Gigabit PoE+ injector delivering up to 30 W (IEEE 802.3at/af) over 100 m of Ethernet. With one passthrough port and one powered port, along with LED status and surge/ESD protection, it's ideal for powering IP cameras, access points, VoIP phones, and other PoE devices without needing PoE switches.



Specifications

Power & Performance

• PoE Output: 30 W Max (IEEE 802.3at/af, Mode A; supports 2-pair feeding 1/2‑3/6+) :contentReference[oaicite:1]{index=1}

• Data Rate: Gigabit Ethernet (10/100/1000 Mbps); up to 100 m transmission range :contentReference[oaicite:2]{index=2}

---

Connectivity

• Ports: 1× GbE Input (data); 1× PoE‑enabled GbE Output :contentReference[oaicite:3]{index=3}

---

Protection & Indicators

• Surge / ESD: Built‑in protection (ESD contact 6 kV/air 8 kV) :contentReference[oaicite:4]{index=4}

• LED Status: Power and PoE activity indicator lights :contentReference[oaicite:5]{index=5}

---

Power Input & Environment

• AC Input: 100–240 V AC → internal DC converter :contentReference[oaicite:6]{index=6}

• Operating Temp: −10 °C to +45 °C; Storage: −40 °C to +70 °C :contentReference[oaicite:7]{index=7}
