The Cudy GS1005PTS1 is a compact, fanless 5‑port gigabit PoE+ switch with a 120 W internal PSU and 1 GbE SFP uplink. It supports VLAN isolation, Extend mode (up to 250 m at reduced speed), and PoE Watchdog power cycling—making it ideal for CCTV, Wi‑Fi, or VoIP deployments in small offices or surveillance stations.



Specifications

Ports & PoE

• 4× Gigabit RJ45 PoE+ Ports: Ports 1–4; Port 1 up to 60 W (4‑pair), Ports 2–4 up to 30 W each; IEEE 802.3af/at compliant :contentReference[oaicite:1]{index=1}

• 1× Uplink GbE + 1× Uplink SFP: 1 GbE RJ45 + 1 GbE SFP :contentReference[oaicite:2]{index=2}

---

Power & Modes

• Total PoE Budget: 120 W internal PSU; auto power management with power‑capped ports :contentReference[oaicite:3]{index=3}

• Switch Modes: VLAN isolates ports 1–4 from uplinks; Extend enables ports 3–4 up to 250 m @10 Mbps; Watchdog auto-reboots silent devices after 5 min inactivity :contentReference[oaicite:4]{index=4}

---

Performance & Reliability

• Switching Capacity: 12 Gbps back‑plane; 8.928 Mpps forwarding rate; MAC table 2K entries; Jumbo frames up to 9 KB :contentReference[oaicite:5]{index=5}

• ESD/Surge Protection: ESD 6 kV contact, 8 kV air; Surge protection: Power DM 2 kV, CM 4 kV; shielded RJ45 ports, metal casing :contentReference[oaicite:6]{index=6}

---

Hardware & Environment

• Dimensions & Weight: 200 × 118 × 44 mm; 645 g; metal chassis; desktop or rack-mountable :contentReference[oaicite:7]{index=7}

• Operating Temp & Humidity: 0–40 °C; Storage −40–70 °C; Humidity 10–90% non‑condensing :contentReference[oaicite:8]{index=8}
